Amphenol PT06A-14-5S(SR), PT Series, 5 Way Cable Mount MIL Spec Circular Connector Plug

Enrgtech Part No: ET13950176
|
Manufacturer Part No:
PT06A-14-5S(SR)
|
Manufacturer: Amphenol

PT06A-14-5S-SR- Amphenol PT06A-14-5S(SR), PT Series, 5 Way Cable Mount MIL Spec Circular Connector Plug

Product Information

The PT06A-14-5S(SR) is a robust MIL Spec Circular Connector Plug from the Amphenol's PT Series, engineered for demanding cable mount applications, offering a high-performing 5-way connectivity solution. Its sturdy build provides superior signal transmission through a five-point connection, ensuring reliable data and power transfer in military-grade environments.

Series:

Mating Type:

Bayonet

Mounting Type:

Cable Mount

Voltage Rating:

1 kV ac

Number of Contacts:

Gender:

Male

Colour:

Green

Termination Method:

Solder

Contact Gender:

Female

Military Standard:

MIL-DTL-26482

Housing Material:

Aluminium

Minimum Operating Temperature:

-55°C

Checking for live stock

The Amphenol PT06A-14-5S(SR) is a cable mount circular connector plug designed for use in demanding military and industrial applications. It belongs to the PT Series and features a shell size of 14, with a bayonet coupling mechanism. The connector has socket contacts, providing a reliable and secure electrical connection. With these features, it finds applications in military, industrial, communication, and power distribution systems, especially in challenging settings.

Key Features of Amphenol PT06A-14-5S(SR), PT Series, 5 Way Cable Mount MIL Spec Circular Connector Plug Include:

MIL Spec Compliance: The PT06A-14-5S(SR) connector adheres to MIL-DTL-5015 specifications, ensuring high-quality performance and compatibility with military equipment and systems.
Robust Construction: The connector is built to withstand harsh environmental conditions. It is created from durable materials and features a rugged shell design, providing excellent moisture, dust, and vibration resistance.
Bayonet Coupling: The coupling mechanism allows for quick and secure mating and unmating of the connector. It ensures a reliable connection even in demanding conditions, making it suitable for applications requiring frequent connections and disconnections.
Socket Contacts: The PT06A-14-5S(SR) connector is equipped with socket contacts, which offer a reliable electrical interface. The contacts are designed to provide low contact resistance, ensuring efficient power and signal transmission.
Cable Mount Design: This connector is specifically designed for cable mount applications, making it easy to install and integrate into various systems. It allows a secure connection between the cable and the equipment, reducing the risk of accidental disconnections.

Application Industries of Amphenol PT06A-14-5S(SR), PT Series, 5-Way Cable Mount MIL Spec Circular Connector Plug:

Military Applications: The rugged design and MIL Spec compliance of the PT06A-14-5S(SR) connector make it suitable for military applications. It can be used in military vehicles, communication systems, and other military equipment, where reliability and durability are crucial.
Industrial Machinery: The connector's robust construction and secure coupling mechanism make it well-suited for industrial machinery. It can be employed in automation systems, robotics, control panels, and other industrial applications that require a reliable electrical connection.
Harsh Environments: With its excellent resistance to moisture, dust, and vibration, the PT06A-14-5S(SR) connector can be utilized in harsh environments such as outdoor installations, transportation equipment, and aerospace applications.
Communications: The connector's reliable socket contacts are ideal for communication systems, including radio equipment, intercom systems, and data transmission devices.
Power Distribution: The PT06A-14-5S(SR) connector can also be used in power distribution applications, providing a secure and efficient connection for power transmission in various industries.

Datasheet(Technical Reference)

PT Series Catalog(Technical Reference)
