Maximum DC Voltage:
220V
Maximum AC Voltage:
415V
Operating Force:
1N
Dimensions:
31 x 33.5 x 76 mm
Maximum Current:
3 A @ 24 V dc, 6 A @ 24 V ac
IP Rating:
IP65
Series:
LS-Titan
Normal State Configuration:
2NC
Length:
31mm
Housing Material:
Cold Climate Insulated Plastic
Width:
33.5mm
Depth:
76mm
Mounting Orientation:
Top
Actuator Type:
Plunger
Contact Type:
Snap Action
Mechanical Life Minimum:
8000000 Operations
Connection Type:
Cage Clamp
Maximum Operating Temperature:
+70°C
Minimum Operating Temperature:
-40°C
Standards Met:
CAS File No 12528, CAS-C22.2, CE, CSA, CSA Class No 3211-03, FS Approval, IEC 60068-2-30, IEC 60068-2-78, IEC EN 61000-4-2, IEC EN 61000-4-5, IEC/EN 60947, IEC/EN 60947-5, IEC/EN 61000-4-6, TUV Approval, UL, UL CCN NKCR, UL File No 508, UL File No E29184
