Schaffner 150 (Dual Load) μH, 600 (Dual Load) μH Common Mode Choke, Max SRF:11 (Dual Load) MHz, 5.5 (Single Load) MHz

RS614-1-02 Schaffner 150 (Dual Load) μH, 600 (Dual Load) μH Common Mode Choke, Max SRF:11 (Dual Load) MHz, 5.5 (Single Load) MHz
Schaffner

Product Information

Maximum DC Resistance:
200 (Dual Load) mΩ, 400 (Single Load) mΩ
Dimensions:
15.5 x 23 x 25mm
Lead Diameter:
0.8mm
Maximum DC Current:
1A
Series:
RS
Minimum Operating Temperature:
-40°C
Length:
15.5mm
Height:
25mm
Depth:
23mm
Inductance:
150 (Dual Load) μH, 600 (Dual Load) μH
Maximum Self Resonant Frequency:
11 (Dual Load) MHz, 5.5 (Single Load) MHz
Mounting Type:
Radial
Lead Pitch:
10mm
Maximum Operating Temperature:
+125°C
Terminal Type:
Radial Leaded
RoHs Compliant
Checking for live stock

This is 150 (Dual Load) μH 600 (Dual Load) μH Common Mode Choke Max SRF:11 (Dual Load) MHz 5.5 (Single Load) MHz manufactured by Schaffner. The manufacturer part number is RS614-1-02. It allows up to 200 (dual load) mω, 400 (single load) mω maximum DC resistance. The given dimensions of the product include 15.5 x 23 x 25mm. Furthermore, the lead has 0.8mm diameter. While it carries 1a of maximum DC current. The product rs, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. Its accurate length is 15.5mm. In addition, the height is 25mm. The product comes in 23mm depth. The product has a 150 (dual load) μh, 600 (dual load) μh inductance value. It provides 11 (dual load) mhz, 5.5 (single load) mhz of maximum self-resonant frequency. The product is available in radial configuration. The lead features 10mm pitch. It has a maximum operating temperature of +125°c. The terminal is a radial leaded type.
