Schaffner 15 (Dual Load) μH, 3.8 (Dual Load) μH Common Mode Choke, Max SRF:27 (Single Load) MHz, 33 (Dual Load) MHz

Enrgtech Part No: ET14064065
|
Manufacturer Part No:
RS612-4-02
|
Manufacturer: Schaffner

RS612-4-02 Schaffner 15 (Dual Load) μH, 3.8 (Dual Load) μH Common Mode Choke, Max SRF:27 (Single Load) MHz, 33 (Dual Load) MHz

Product Information

Maximum DC Resistance:

10 (Dual Load) mΩ, 20 (Single Load) mΩ

Dimensions:

12.5 x 18 x 20mm

Lead Diameter:

0.8mm

Maximum DC Current:

Series:

Minimum Operating Temperature:

-40°C

Length:

12.5mm

Height:

20mm

Depth:

18mm

Inductance:

15 (Dual Load) μH, 3.8 (Dual Load) μH

Maximum Self Resonant Frequency:

27 (Single Load) MHz, 33 (Dual Load) MHz

Mounting Type:

Radial

Checking for live stock

This is 15 (Dual Load) μH 3.8 (Dual Load) μH Common Mode Choke Max SRF:27 (Single Load) MHz 33 (Dual Load) MHz manufactured by Schaffner. The manufacturer part number is RS612-4-02. It allows up to 10 (dual load) mω, 20 (single load) mω maximum DC resistance. The given dimensions of the product include 12.5 x 18 x 20mm. Furthermore, the lead has 0.8mm diameter. While it carries 4a of maximum DC current. The product rs, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. Its accurate length is 12.5mm. In addition, the height is 20mm. The product comes in 18mm depth. The product has a 15 (dual load) μh, 3.8 (dual load) μh inductance value. It provides 27 (single load) mhz, 33 (dual load) mhz of maximum self-resonant frequency. The product is available in radial configuration. The lead features 15mm pitch. It has a maximum operating temperature of +125°c. The terminal is a radial leaded type.
