Dimensions:
24 x 10 x 15.8mm
Electrical Life:
20000 operations
Application:
Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies
Coil Resistance:
2.88 kΩ
Life:
Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations
Standards Met:
CSA, CUL, CULus, PTI 325V, TV-8, UL, VDE
Coil Power:
200mW
Isolation Coil To Contact:
5000Vrms
Maximum Operating Temperature:
+70°C
Terminal Type:
PCB Pin
Coil Voltage:
24 V dc
Operating Temperature Range:
-40 → +70°C
Switching Current:
16 A
Contact Configuration:
SPNO
Depth:
10mm
Relay Switching Classification:
Latching Relay
Features:
Small Polarised Power Relays, 1 Form A 16 A
Mounting Type:
PCB Mount
Length:
24mm
Height:
15.8mm
Maximum Switching Voltage AC:
277V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
4.432 kVA
Number of Poles:
1
Contact Material:
Silver Alloy
