This is SPNO PCB Mount Latching Relay 6V dc For Use In Power Applications manufactured by RS Pro. The manufacturer part number is 476-567. The given dimensions of the product include 39 x 30.2 x 15mm. The coil voltage of the product is 6 v dc. Applications Information involves power. It holds up to 24 ω coil resistance. It is capable of doing 1000000 (mechanical) cycles in a lifetime . The product complies with all safety standards, such as rohs compliant. Robust coil power of 3w. The product has 4kv ac isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a through hole type. The product has -40 → +70°c of operating temperature range. It is integrated with 50 a switching current. The contact is equipped with spno configuration. The product comes in 15mm depth. The splendid features of the product include capacitor load up to 200 μf (min inrush current at 500 a/10 μs), creepage distance 8 mm, lamp load up to 5000 w, maximum switching capability up to 50 a, wash tight, 4 kv dielectric strength (between coil & contacts). The product is available in pcb mount configuration. Its accurate length is 39mm. In addition, the height is 30.2mm. It has a maximum AC switching voltage of 440v ac. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 12.5 kva. The product is made from sturdy silver alloy materials.
For more information please check the datasheets.
