TDK-Lambda CCG15 13.2W Isolated DC-DC Converter Through Hole, Vin 9 → 36 V dc, Vout 3.3V dc

CCG-15-24-03S TDK-Lambda CCG15 13.2W Isolated DC-DC Converter Through Hole, Vin 9 → 36 V dc, Vout 3.3V dc
TDK-Lambda

Product Information

Number of Outputs:
1
Output Voltage Adjustment Range:
4.5 → 5.5V
Load Regulation:
20mV
Isolation Voltage:
500V dc
Standards Met:
CE, EN 60950-1, UL/CSA 60950-1
Mounting Type:
Through Hole
Width:
25.4mm
Maximum Temperature:
+85°C
Series:
CCG15
Input Voltage Range:
9 → 36 V dc
Length:
25.4mm
Efficiency:
85%
Depth:
9.9mm
Output Voltage:
3.3V dc
Minimum Temperature:
-40°C
Input Voltage Nominal:
9 → 36 V dc
Power Rating:
13.2W
Output Current:
4A
RoHs Compliant
Checking for live stock

This is CCG15 13.2W Isolated DC-DC Converter Through Hole Vin 9 → 36 V dc Vout 3.3V dc manufactured by TDK-Lambda. The manufacturer part number is CCG-15-24-03S. Additionally, the product is supplied with 1 outputs. It has 4.5 → 5.5v of output voltage adjustment range. Load Regulation - 20mv. It has 500v dc isolation voltage. The product complies with all safety standards, such as ce, en 60950-1, ul/csa 60950-1. The product is available in through hole configuration. Furthermore, the product is 25.4mm wide. The product has +85°c maximum temperature. The product ccg15, is a highly preferred choice for users. It has 9 → 36 v dc of input voltage range. Its accurate length is 25.4mm. It is a highly efficient product with an 85% of high efficiency. The product comes in 9.9mm depth. Features a 3.3v dc output voltage. While its minimum temperature is -40°c. It has 9 → 36 v dc of nominal input voltage. Feature 13.2w of power rating. It carries 4a output current.

pdf icon
Datasheet(Technical Reference)
pdf icon
CCG Series Instruction Manual(Technical Reference)
