This is Dual Schmitt Trigger CMOS Inverter 1.65 → 5.5 V 6-Pin X2-DFN1409 manufactured by DiodesZetex. The manufacturer part number is 74LVC2G14FX4-7. The given dimensions of the product include 1.45 x 0.95 x 0.35mm. The logic family is lvc. Furthermore, the product is 0.9mm wide. It carries schmitt trigger input type. On the other hand, it is featured with 32ma of max. low level output current. While a -32ma of maximum high level output current. It provides up to 4.7 ns @ 50 pf maximum propagation delay time. While its minimum operating supply voltage is 1.65 v. Furthermore, it has apush-pull output. The package is a sort of x2-dfn1409. It consists of 2 elements per chip. It has a maximum operating temperature of +125 °c. Its accurate length is 1.4mm. It contains 6 pins. The product is available in surface mount configuration. It has 5.5 v maximum operating supply voltage. The primary function of logic includes inverter. In addition, the height is 0.37mm. Whereas, the minimum operating temperature of the product is -40 °c. Schmitt Trigger Input - yes. Features 50pf of propagation delay test condition.
For more information please check the datasheets.
