Number of Outputs per Element:
2
Output Signal Type:
Single Ended
Dimensions:
2.1 x 2.4 x 0.8mm
Mounting Type:
Surface Mount
Input Signal Type:
Differential
Power Supply Type:
Single
Number of Channels per Chip:
2
Typical Single Supply Voltage:
1.65 → 5.5 V
Height:
0.8mm
Width:
2.4mm
Length:
2.1mm
Package Type:
US
Minimum Operating Temperature:
-40 °C
Number of Inputs per Element:
2
Configuration:
Dual SPST
Maximum Operating Temperature:
+85 °C
Pin Count:
8
Switch Type:
Analogue
Manufacturer Standard Lead Time:
17 Weeks
Detailed Description:
2 Circuit IC Switch 1:1 850mOhm US8
-3db Bandwidth:
240MHz
Operating Temperature:
-40°C ~ 85°C (TA)
Channel-to-Channel Matching (ΔRon):
50mOhm
Package / Case:
8-VFSOP (0.091", 2.30mm Width)
Switch Time (Ton, Toff) (Max):
7.5ns, 17ns
Current - Leakage (IS(off)) (Max):
10nA
Base Part Number:
FSA1259
Multiplexer/Demultiplexer Circuit:
1:1
Manufacturer:
ON Semiconductor
Channel Capacitance (CS(off), CD(off)):
21pF
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
Switch Circuit:
SPST - NO
Number of Circuits:
2
Mounting Type:
Surface Mount
Crosstalk:
-73dB @ 1MHz
On-State Resistance (Max):
850mOhm
Supplier Device Package:
US8
Charge Injection:
15pC
Packaging:
Cut Tape (CT)
