Analog Devices AD8221ARZ, Instrumentation Amplifier, 0.06mV Offset 825kHz, 8-Pin SOIC

AD8221ARZ Analog Devices , Instrumentation Amplifier, 0.06mV Offset 825kHz, 8-Pin SOIC
AD8221ARZ
Analog Devices

Product Information

Minimum CMRR:
130dB
Maximum Input Offset Voltage:
0.06mV
Typical Dual Supply Voltage:
±12 V, ±15 V, ±3 V, ±5 V, ±9 V
Typical Gain Bandwidth Product:
825kHz
Dimensions:
5 x 4 x 1.5mm
Mounting Type:
Surface Mount
Maximum Input Resistance:
100GΩ
Power Supply Type:
Dual
Rail to Rail:
No
Height:
1.5mm
Width:
4mm
Length:
5mm
Package Type:
SOIC
Minimum Operating Temperature:
-40 °C
Maximum Supply Current:
1 mA
Maximum Operating Temperature:
+125 °C
Pin Count:
8
RoHs Compliant
Checking for live stock

This is Instrumentation Amplifier 0.06mV Offset 825kHz 8-Pin SOIC manufactured by Analog Devices. The manufacturer part number is AD8221ARZ. It is designed with a minimum 130db CMRR . It has a maximum 0.06mv input offset voltage . While ±12 v, ±15 v, ±3 v, ±5 v, ±9 v is the typical dual supply voltage. Features 825khz typical gain bandwidth. The given dimensions of the product include 5 x 4 x 1.5mm. The product is available in surface mount configuration. It has a maximum 100gω input resistance . It is a type of dual power supply. Rail to rail options include no. In addition, the height is 1.5mm. Furthermore, the product is 4mm wide. Its accurate length is 5mm. The package is a sort of soic. Whereas, the minimum operating temperature of the product is -40 °c. Moreover, it has a maximum 1 ma supply current . It has a maximum operating temperature of +125 °c. It contains 8 pins.

pdf icon
Instrument Amp Single 18V 8-Pin SOIC(Technical Reference)
pdf icon
AD8221 SPICE Macro Model(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
