Analog Devices AD595CQ, Thermocouple Amplifier 15kHz, 5 V, 14-Pin CDIP

AD595CQ Analog Devices , Thermocouple Amplifier 15kHz, 5 V, 14-Pin CDIP
AD595CQ
Analog Devices

Product Information

Typical Dual Supply Voltage:
±15V
Typical Gain Bandwidth Product:
15kHz
Dimensions:
19.55 x 6.6 x 3.76mm
Mounting Type:
Through Hole
Power Supply Type:
Dual, Single
Rail to Rail:
No
Height:
3.76mm
Typical Single Supply Voltage:
5 V
Width:
6.6mm
Length:
19.55mm
Package Type:
CDIP
Minimum Operating Temperature:
-55 °C
Maximum Operating Temperature:
+125 °C
Pin Count:
14
Checking for live stock

This is Thermocouple Amplifier 15kHz 5 V 14-Pin CDIP manufactured by Analog Devices. The manufacturer part number is AD595CQ. While ±15v is the typical dual supply voltage. Features 15khz typical gain bandwidth. The given dimensions of the product include 19.55 x 6.6 x 3.76mm. The product is available in through hole configuration. It is a type of dual, single power supply. Rail to rail options include no. In addition, the height is 3.76mm. It has a typical single supply voltage of 5 v. Furthermore, the product is 6.6mm wide. Its accurate length is 19.55mm. The package is a sort of cdip. Whereas, the minimum operating temperature of the product is -55 °c. It has a maximum operating temperature of +125 °c. It contains 14 pins.
