Number of Outputs:
1
Ripple And Noise:
<50mV Pk-Pk
Output Current:
4.2A
Standards Met:
CE, cRUus, cULus, RoHS Compliant
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+60°C
Series:
SDP
Electrical Phase:
1
Special Features:
Continuous Short Circuit Protection, Low Output Noise
AC or DC Input Voltage:
ac, dc
Height:
75mm
Width:
75mm
Depth:
96.7mm
MTBF:
>500000h
Output Voltage:
24V dc
Minimum Temperature:
-10°C
AC or DC Output Voltage:
dc
Power Rating:
100W
Type:
Switched Mode
Input Voltage:
85 → 132 V ac, 176 → 264 V ac / 90 → 375V dc
HTSUS:
8504.40.9520
RoHS Status:
RoHS Compliant
Power (Watts):
101W
Current - Output (Max):
4.2A
Approval Agency:
CE, cULus, cURus
Input Type:
AC or DC
Applications:
Hazardous Locations, Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
88%
DC Voltage - Input (Max):
375V
Package:
Bulk
DC Voltage - Input (Min):
210V
Minimum Load Required:
-
Size / Dimension:
3.80" L x 2.85" W x 2.95" H (96.5mm x 72.4mm x 74.9mm)
standardLeadTime:
12 Weeks
AC Voltage - Input:
85 ~ 132 VAC, 176 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Adjustable Output, IP20
Series:
SDP
Operating Temperature:
-10°C ~ 70°C (With Derating)
Base Product Number:
SDP4
Number of Outputs:
1
ECCN:
EAR99
