Number of Outputs:
1
Ripple And Noise:
40mV Pk-Pk
Output Current:
2.5A
Dimensions:
32 x 90 x 106mm
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+70°C
Series:
QUINT4-PS/1AC/24DC/2.5/PT
Electrical Phase:
1
Special Features:
Heavy Loads with Dynamic Boost, Monitoring Indicates Critical Operating States Before Errors Occur, Power Range of up to 100 W
AC or DC Input Voltage:
ac, dc
Height:
106mm
Width:
32mm
Depth:
90mm
MTBF:
1347000 h @ 25 °C, 295000 h @ 60 °C, 734000 h @ 40 °C
Output Voltage:
24V dc
Minimum Temperature:
-25°C
AC or DC Output Voltage:
dc
Power Rating:
60W
Type:
Switch Mode
Input Voltage:
230V ac
HTSUS:
8504.40.9520
RoHS Status:
ROHS3 Compliant
Voltage - Output 1:
24V
Power (Watts):
60W
Current - Output (Max):
2.5A
Approval Agency:
CB, CE, UL
Input Type:
AC or DC
Applications:
ITE (Commercial), Laboratory
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
REACH Status:
REACH Affected
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
92.6%
DC Voltage - Input (Max):
250V
Package:
Bulk
DC Voltage - Input (Min):
110V
Minimum Load Required:
-
Size / Dimension:
3.54" L x 1.26" W x 4.17" H (90.0mm x 32.0mm x 106.0mm)
standardLeadTime:
8 Weeks
Voltage - Isolation:
4 kV
AC Voltage - Input:
100 ~ 240 VAC
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
Adjustable Output, IP20, PFC, Universal Input
Series:
Quint
Operating Temperature:
-25°C ~ 70°C (With Derating)
Number of Outputs:
1
ECCN:
EAR99
