Current Rating:
4A
Minimum Operating Temperature:
-40°C
IP Rating:
IP67
Series:
SACC
Body Orientation:
Angled
Voltage Rating:
48 V ac, 60 V dc
Coding:
A
Housing Material:
Brass
Plug/Socket:
Socket
Connector Size:
M8
Shielded/Unshielded:
Unshielded
Number of Contacts:
3
Outer Diameter:
3.5 → 5mm
Maximum Operating Temperature:
+85°C
Contact Material:
CuZn
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
48VAC, 60VDC
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
3
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polybutylene Terephthalate (PBT)
Shielding:
-
Cable Opening:
0.138" ~ 0.197" (3.50mm ~ 5.00mm)
Shell Material:
Brass
REACH Status:
REACH Affected
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 HB
Package:
Bulk
Shell Size - Insert:
M8-3
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Termination:
Solder Cup
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
Nickel
Color:
Black, Silver
Series:
SACC
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
