3M 101 Series 1.27mm Pitch 14 Way Mini D Ribbon IDC Connector, Plug, Steel Shell

10114-6000-EL 3M 101 Series 1.27mm Pitch 14 Way Mini D Ribbon IDC Connector, Plug, Steel Shell
3M

Product Information

Series:
101
Current Rating:
1A
Dimensions:
18.2 x 12.7 x 9.1mm
Gender:
Male
Body Orientation:
Right Angle
Length:
18.2mm
Housing Material:
Steel
Width:
12.7mm
Depth:
9.1mm
Contact Plating:
Gold over Nickel
Pitch:
1.27mm
Number of Contacts:
14
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-20°C
Contact Material:
Beryllium Copper
RoHs Compliant
Checking for live stock

This is 101 Series 1.27mm Pitch 14 Way Mini D Ribbon IDC Connector Plug Steel Shell manufactured by 3M. The manufacturer part number is 10114-6000 EL. The product 101, is a highly preferred choice for users. The product has a current rating of 1a. The given dimensions of the product include 18.2 x 12.7 x 9.1mm. In addition, male is the available "Gender" of the product. It has right angle body orientation. Its accurate length is 18.2mm. The product also features robust steel housing material. Furthermore, the product is 12.7mm wide. The product comes in 9.1mm depth. The high-quality gold over nickel is used as contact plating material. Moreover, the product is 1.27mm. The product contains 14 contacts. It has a maximum operating temperature of +85°c. Whereas, the minimum operating temperature of the product is -20°c. The product is made from sturdy beryllium copper materials.

pdf icon
101 Series MDR Connectors Data Sheet(Technical Reference)
pdf icon
10960-2000 MDR Assembly Press - Instructions(Technical Reference)
