TE Connectivity AMP Connectors 2178710-4

2178710-4 TE Connectivity AMP Connectors
2178710-4
TE Connectivity AMP Connectors

Product Information

Contact Finish - Mating:
Tin
Style:
Board to Board or Cable
Detailed Description:
4 Position Receptacle Connector 0.100" (2.54mm) Through Hole Tin
Operating Temperature:
-30°C ~ 85°C
Contact Finish Thickness - Post:
118.1µin (3.00µm)
Number of Positions:
4
Base Part Number:
2178710
Insulation Height:
0.157" (4.00mm)
Insulation Color:
Black
Contact Length - Post:
0.122" (3.10mm)
Applications:
General Purpose, Telecommunications
Number of Rows:
2
Manufacturer:
TE Connectivity AMP Connectors
Voltage Rating:
100VDC
Row Spacing - Mating:
0.100" (2.54mm)
Connector Type:
Receptacle
Number of Positions Loaded:
All
Contact Finish Thickness - Mating:
118.1µin (3.00µm)
Fastening Type:
Push-Pull
Termination:
Kinked Pin, Solder
Pitch - Mating:
0.100" (2.54mm)
Mounting Type:
Through Hole
Series:
Micro-MaTch
Packaging:
Cut Tape (CT)
Customer Reference:
Contact Type:
Forked
Contact Finish - Post:
Tin
Insulation Material:
Polybutylene Terephthalate (PBT)
Contact Material:
Brass
Checking for live stock

This is manufactured by TE Connectivity AMP Connectors. The manufacturer part number is 2178710-4. It has nice contact finishing of tin. Additionally, the product is designed with board to board or cable Style. It features 4 position receptacle connector 0.100" (2.54mm) through hole tin. The product has -30°c ~ 85°c operating temperature range. Additionally, it features 118.1µin (3.00µm) of post thickness. The product carries possible position value of 4. Base Part Number: 2178710. 0.157" (4.00mm) of insulation height. In addition, black is the insulation color of the product. 0.122" (3.10mm) is the given possible contact length (post) values. The product is widely employed in general purpose, telecommunications. It comes in 2 of rows. The te connectivity amp connectors's product offers user-desired applications. Moreover, the product has a nominal 100vdc voltage rating. It carries 0.100" (2.54mm) of row spacing. receptacle Connector type offer robust functionality. However, all is the Number of Positions Loaded. However, 118.1µin (3.00µm) is the "Contact Finish Thickness - Mating" of the product. Furthermore, push-pull is the Fastening Type of the product. The product features kinked pin, solder termination style. It has 0.100" (2.54mm) of pitch-mating value. The product is available in through hole configuration. The product micro-match, is a highly preferred choice for users. In addition, cut tape (ct) is the available packaging type of the product. It has typical contact type of forked. It has possible tin contact post finishing. It has a robust polybutylene terephthalate (pbt) insulation material. The product is made from sturdy brass materials.

pdf icon
Mult Devs - End of Life 28/AUG/2020(PCN Obsolescence/ EOL)
