Number of Contacts:
4
Current Rating:
3A
Dimensions:
10.16 x 2.95 x 2.54mm
Mounting Type:
Through Hole
Voltage Rating:
100 V ac, 150 V dc
Termination Method:
Solder
Length:
10.16mm
Housing Material:
Glass Fibre Reinforced PCT
Width:
2.95mm
Depth:
2.54mm
3D Model:
https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=21806&DisplayLogo=False
Pitch:
2.54mm
Contact Plating:
Gold, Tin
Contact Material:
Beryllium Copper, Brass
Maximum Operating Temperature:
+125°C
Minimum Operating Temperature:
-55°C
Orientation:
Right Angle
Contact Finish - Mating:
Gold
Style:
Board to Board
Contact Finish - Post:
Tin
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Contact Finish Thickness - Post:
-
Number of Positions:
4
Insulation Height:
0.100" (2.54mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
edacadModel:
801-87-004-20-002101 Models
Applications:
-
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4125844
Contact Shape:
Circular
Mated Stacking Heights:
-
Voltage Rating:
-
Row Spacing - Mating:
-
Connector Type:
Socket
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Contact Finish Thickness - Mating:
Flash
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
11 Weeks
Current Rating (Amps):
3A
Contact Length - Post:
0.126" (3.20mm)
Pitch - Mating:
0.100" (2.54mm)
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole, Right Angle
Series:
801
Packaging:
Bulk
Insulation Material:
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Contact Type:
Female Socket
Contact Material:
Beryllium Copper
Base Product Number:
801-87
ECCN:
EAR99
