Housing Material:
Polyamide
Number of Contacts:
9
Orientation:
0°
Wire Connection Method:
Screw Connection with Tension Sleeve
Minimum Wire Size mm²:
0.14mm²
Series:
IMC
Colour:
Green
Minimum Wire Size AWG:
28 AWG
Length:
18.45mm
Current:
8A
Width:
35.08 mm
Depth:
11.1mm
Number of Rows:
1
Standards/Approvals:
cULus, CHINA RoHS, IEC 60664-1:2007-04, VDE, ISO 6988:1985-02, IEC 60999-1:1999-11, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-3-1:2002-02, IEC 60512-9-1:2010-03, IEC 60068-2-6:2007-12
Voltage:
160 V
Pitch:
3.81mm
Maximum Wire Size AWG:
16 AWG
Product Type:
PCB Connector
Maximum Wire Size mm²:
1.5mm²
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M2
Wire Strip Length:
7mm
Type:
Plug, Male Pins
Number of Positions:
9
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.14-1.5mm²
title:
1857951
Plug Wire Entry:
180°
Insulation Height:
0.437" (11.10mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Number of Levels:
1
Wire Gauge or Range - AWG:
14-30 AWG
Voltage - UL:
300 V
Torque - Screw:
0.22-0.25 Nm (1.9-2.2 Lb-In)
standardLeadTime:
7 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
320 V
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON IMC
Positions Per Level:
9
Packaging:
Bulk
Header Orientation:
-
Current - UL:
8 A
Pitch:
0.150" (3.81mm)
Contact Material:
-
ECCN:
EAR99
