HARTING 14110410002000

14110410002000 HARTING
14110410002000
14110410002000
HARTING

Product Information

Shrouded/Unshrouded:
Shrouded
Current Rating:
2.7A
Mounting Type:
Surface Mount
Series:
Har-Flexicon
Body Orientation:
Straight
Termination Method:
SMT
Number of Rows:
1
Pitch:
1.27mm
Number of Contacts:
4
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature:
-40°C ~ 125°C
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
4
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.139" (3.53mm)
REACH Status:
REACH Unaffected
edacadModel:
14110410002000 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4835048
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
-
Number of Levels:
1
Contact Tail Length:
-
Voltage - UL:
16 V
Torque - Screw:
-
standardLeadTime:
13 Weeks
Contact Mating Finish:
Gold
Ingress Protection:
-
Features:
Board Guide, Solder Retention
Mounting Type:
Surface Mount
Color:
Black
Series:
har-flexicon®
Positions Per Level:
4
Header Orientation:
90°, Right Angle
Current - UL:
2 A
Wire Gauge or Range - AWG:
-
Pitch:
0.050" (1.27mm)
Contact Material:
Copper Alloy
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is manufactured by HARTING. The manufacturer part number is 14110410002000. It is supplied as shrouded. The product has a current rating of 2.7a. The product is available in surface mount configuration. The product har-flexicon, is a highly preferred choice for users. It has straight body orientation. It allows smt termination method. It comes in 1 of rows. Moreover, the product is 1.27mm. The product contains 4 contacts. It is assigned with possible HTSUS value of 8536.69.4040. The product is rohs3 compliant. Moreover, it has solder terminal style. The product also features robust liquid crystal polymer (lcp), glass filled housing material. The product has -40°c ~ 125°c operating temperature range. It comes in header, male pins, shrouded (4 side) configuration. The product carries possible position value of 4. 0.139" (3.53mm) of insulation height. In addition, it is reach unaffected. It carries ul94 v-0 of material flammability rating. It is shipped in tape & reel (tr) package . Its typical moisture sensitivity level is 1 (unlimited). The product carries 1 levels. While 16 v is the typical voltage of the product. It has a long 13 weeks standard lead time. The mating finish of the contact is gold. The splendid features of the product include board guide, solder retention. It has a classic black colour. The product har-flexicon®, is a highly preferred choice for users. It has 4 positions each level. The product has a 90°, right angle of a header orientation. The typical current includes 2 a. Moreover, the product is 0.050" (1.27mm). The product is made from sturdy copper alloy materials. The product is designated with the ear99 code number.

pdf icon
har-flexicon Horizontal 1.27 Male Connector Drawing(Technical Reference)
pdf icon
har-flexicon Horizontal 1.27 Male Connector Data Sheet(Technical Reference)
pdf icon
14111200301(Datasheets)
pdf icon
14110410002000 Prod Declaration Cert(Datasheets)
pdf icon
14110410002333(Product Drawings)
