Analog Devices AD9135BCPZ, 2-channel 11 bit Parallel DAC, 2.8Gsps, 88-Pin LFCSP VQ

AD9135BCPZ Analog Devices , 2-channel 11 bit Parallel DAC, 2.8Gsps, 88-Pin LFCSP VQ
Analog Devices

Product Information

Conversion Rate:
2.8Gsps
Integral Nonlinearity Error:
±0.35LSB
Digital Interface Type:
Parallel & Serial (LVDS/SPI)
Dimensions:
12.1 x 12.1 x 0.85mm
Mounting Type:
Surface Mount
Number of DAC Channels:
2
Power Supply Type:
Single
Maximum Settling Time:
20ns
Typical Single Supply Voltage:
1.2 V, 1.8 V, 3.3 V
Height:
0.85mm
Width:
12.1mm
Length:
12.1mm
Package Type:
LFCSP VQ
Minimum Operating Temperature:
-40 °C
Voltage Reference:
Internal
Maximum Operating Temperature:
+85 °C
Resolution:
11 bit
Pin Count:
88
RoHs Compliant
Checking for live stock

This is 2-channel 11 bit Parallel DAC 2.8Gsps 88-Pin LFCSP VQ manufactured by Analog Devices. The manufacturer part number is AD9135BCPZ. Its conversion rate is 2.8gsps . Its integral nonlinearity error is ±0.35lsb . Additionally, the product has a/an parallel & serial (lvds/spi) type digital interface . The given dimensions of the product include 12.1 x 12.1 x 0.85mm. The product is available in surface mount configuration. Additionally, it includes 2 standard DAC channels . It is a type of single power supply. The product has a maximum 20ns setting time . It has a typical single supply voltage of 1.2 v, 1.8 v, 3.3 v. In addition, the height is 0.85mm. Furthermore, the product is 12.1mm wide. Its accurate length is 12.1mm. The package is a sort of lfcsp vq. Whereas, the minimum operating temperature of the product is -40 °c. The product has internal voltage reference. It has a maximum operating temperature of +85 °c. Features 11 bit resolution. It contains 88 pins.

pdf icon
Datasheet(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search AD9135BCPZ on website for other similar products.
We accept all major payment methods for all products including ET14003636. Please check your shopping cart at the time of order.
You can order Analog Devices brand products with AD9135BCPZ directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in General Purpose DACs category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Analog Devices AD9135BCPZ, 2-channel 11 bit Parallel DAC, 2.8Gsps, 88-Pin LFCSP VQ. You can also check on our website or by contacting our customer support team for further order details on Analog Devices AD9135BCPZ, 2-channel 11 bit Parallel DAC, 2.8Gsps, 88-Pin LFCSP VQ.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET14003636 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Analog Devices" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14003636.
Yes. We ship AD9135BCPZ Internationally to many countries around the world.
