Dimensions:
16.59 x 2.06 x 8.25mm
Mounting Type:
Through Hole
Operating Temperature Range:
-40 → +150 °C
Maximum Operating Temperature:
+150 °C
Input Voltage Range:
11.4 → 15 V
Minimum Operating Temperature:
-40 °C
Output Voltage Range:
-1.3 → 530 V
Height:
8.25mm
Typical Operating Supply Voltage:
12 V
Width:
2.06mm
Length:
16.59mm
Package Type:
eSIP-16J
Maximum Output Voltage:
530 V
Minimum Input Voltage:
11.4 V
Minimum Output Voltage:
-1.3 V
Output Current Range:
Maximum of 7.7 A
Maximum Output Current:
7.7A
Pin Count:
13
Maximum Input Voltage:
15 V
HTSUS:
8542.39.0001
RoHS Status:
RoHS Compliant
Current - Output / Channel:
-
Supplier Device Package:
eSIP-16J
Operating Temperature:
-40°C ~ 150°C (TJ)
Package / Case:
16-SSIP, 13 Leads, Exposed Pad, Formed Leads
REACH Status:
REACH Unaffected
edacadModel:
LCS701HG Models
Applications:
General Purpose
Interface:
On/Off
Package:
Tube
Load Type:
Inductive
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
8 Weeks
Features:
Auto Restart, Slew Rate Controlled
Mounting Type:
Through Hole
Series:
HiperLCS™
Voltage - Load:
11.4V ~ 15V
Fault Protection:
Current Limiting, Over Temperature, Over Voltage, Short Circuit, UVLO
Voltage - Supply:
11.4V ~ 15V
Current - Peak Output:
7.7A
Rds On (Typ):
1Ohm
Output Configuration:
Half Bridge
edacadModelUrl:
/en/models/2766018
Technology:
Power MOSFET
Base Product Number:
LCS701
ECCN:
EAR99
