Hirose FH12 1mm Pitch 8 Way Right Angle SMT Female FPC Connector, ZIF Bottom Contact

FH12-8S-1SH-55- Hirose FH12 1mm Pitch 8 Way Right Angle SMT Female FPC Connector, ZIF Bottom Contact
FH12-8S-1SH(55)
FH12-8S-1SH(55)
ET13980277
Hirose

Product Information

Current Rating:
500mA
Termination Type:
ZIF Bottom Contact
Mounting Type:
Surface Mount
Voltage Rating:
50 V ac
Gender:
Female
Body Orientation:
Right Angle
Pitch:
1mm
Termination Method:
Solder
Housing Material:
PPS·Polyamide
Number of Rows:
1
Contact Plating:
Gold
Series:
FH12
Number of Contacts:
8
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
Contact Material:
Phosphor Bronze
RoHs Compliant
Checking for live stock

This is FH12 1mm Pitch 8 Way Right Angle SMT Female FPC Connector ZIF Bottom Contact manufactured by Hirose. The manufacturer part number is FH12-8S-1SH(55). The product has a current rating of 500ma. The product is designed with a zif bottom contact termination. The product is available in surface mount configuration. Moreover, the product has a nominal 50 v ac voltage rating. In addition, female is the available "Gender" of the product. It has right angle body orientation. Moreover, the product is 1mm. It allows solder termination method. The product also features robust pps·polyamide housing material. It comes in 1 of rows. The high-quality gold is used as contact plating material. The product fh12, is a highly preferred choice for users. The product contains 8 contacts. It has a maximum operating temperature of +85°c. Whereas, the minimum operating temperature of the product is -40°c. The product is made from sturdy phosphor bronze materials.

pdf icon
Datasheet(Technical Reference)
pdf icon
FH12 1.0mm FPC/FFC connector - drawing(Technical Reference)
