Murata Power Solutions Inc. 30201AC

30201AC Murata Power Solutions Inc.
Murata Power Solutions Inc.

Product Information

Ratings:
-
HTSUS:
8504.50.8000
RoHS Status:
ROHS3 Compliant
Inductance Frequency - Test:
1 MHz
Operating Temperature:
-40°C ~ 130°C
Package / Case:
2-SMD
Tolerance:
±20%
Shielding:
Shielded
DC Resistance (DCR):
0.35mOhm Max
Height - Seated (Max):
0.195" (4.96mm)
Type:
Wirewound
REACH Status:
REACH Unaffected
edacadModel:
30201AC Models
Inductance:
191 nH
edacadModelUrl:
/en/models/3991695
Package:
Tape & Reel (TR)
Size / Dimension:
0.276" L x 0.276" W (7.00mm x 7.00mm)
Current - Saturation (Isat):
22A
standardLeadTime:
18 Weeks
Material - Core:
-
Current Rating (Amps):
22 A
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Frequency - Self Resonant:
-
Mounting Type:
Surface Mount
Series:
3000A
Supplier Device Package:
-
Q @ Freq:
-
Base Product Number:
30
ECCN:
EAR99
Checking for live stock

This is manufactured by Murata Power Solutions Inc.. The manufacturer part number is 30201AC. It is assigned with possible HTSUS value of 8504.50.8000. The product is rohs3 compliant. 1 mhz is its inductance frequency value. The product has -40°c ~ 130°c operating temperature range. Moreover, the product comes in 2-smd. It features ±20% of tolerance value. Furthermore, the product is shielded with shielded. It allows DC resistance of 0.35mohm max. It has the maximum seated height of 0.195" (4.96mm). It comes in wirewound configuration. In addition, it is reach unaffected. The product has a 191 nh inductance value. It is shipped in tape & reel (tr) package . The product's diameters include 0.276" l x 0.276" w (7.00mm x 7.00mm). It has a 22a saturation current. It has a long 18 weeks standard lead time. Additionally, the product's output is 22 a. Its typical moisture sensitivity level is 1 (unlimited). The product is available in surface mount configuration. The product 3000a, is a highly preferred choice for users. Moreover, it corresponds to 30, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
3000A Series(Datasheets)
pdf icon
3000A.pdf(3D Drawings)
