EPCOS - TDK Electronics B66483K0000X197

B66483K0000X197 EPCOS - TDK Electronics
EPCOS - TDK Electronics

Product Information

HTSUS:
8504.90.9630
RoHS Status:
ROHS3 Compliant
Width:
0.551" (14.00mm)
Effective Permeability (µe):
1260
Tolerance:
±25%
Minimum Core Cross Section (Amin) mm²:
55
Finish:
Uncoated
Effective Length (le) mm:
25.1
Effective Magnetic Volume (Ve) mm³:
1500
Material:
N97
REACH Status:
REACH Unaffected
Gap:
Ungapped
edacadModel:
B66483K0000X197 Models
edacadModelUrl:
/en/models/11488300
Package:
Box
Moisture Sensitivity Level (MSL):
Not Applicable
Length:
0.787" (20.00mm)
standardLeadTime:
11 Weeks
Diameter:
-
Core Factor (ΣI/A) mm⁻¹:
0.42
Series:
I20/2.3/14
Effective Area (Ae) mm²:
59.8
Supplier Device Package:
I 20 x 2.3 x 14
Height:
0.091" (2.30mm)
Inductance Factor (Al):
3.77 µH
ECCN:
EAR99
Checking for live stock

This is manufactured by EPCOS - TDK Electronics. The manufacturer part number is B66483K0000X197. It is assigned with possible HTSUS value of 8504.90.9630. The product is rohs3 compliant. Furthermore, the product is 0.551" (14.00mm) wide. Features effective permeability of 1260. It features ±25% of tolerance value. Its minimum core cross-section is 55. A quality product with a nice uncoated finish. A 25.1 of effective length. It features 1500 effective magnetic volume. The product is made from highly stable and reliable n97. In addition, it is reach unaffected. Gap Options: ungapped. It is shipped in box package . Its typical moisture sensitivity level is not applicable. Its accurate length is 0.787" (20.00mm). It has a long 11 weeks standard lead time. The product i20/2.3/14, is a highly preferred choice for users. Features 59.8 effective area. i 20 x 2.3 x 14 is the supplier device package value. In addition, the height is 0.091" (2.30mm). It carries 3.77 µh of inductance factor. The product is designated with the ear99 code number.
