Analog Devices Inc. DC3020A

DC3020A Analog Devices Inc.
DC3020A
Analog Devices Inc.

Product Information

Main Purpose:
DC/DC, Step Down
HTSUS:
8543.70.9860
RoHS Status:
ROHS3 Compliant
Voltage - Input:
5.8V ~ 42V
Frequency - Switching:
2MHz
REACH Status:
REACH Unaffected
Current - Output:
5A
Manufacturer:
Analog Devices Inc.
Board Type:
Fully Populated
Moisture Sensitivity Level (MSL):
Not Applicable
standardLeadTime:
10 Weeks
Regulator Topology:
Buck
Utilized IC / Part:
LT8637
Series:
-
Voltage - Output:
5V
Packaging:
Bulk
Supplied Contents:
Board(s)
ECCN:
EAR99
Outputs and Type:
1, Non-Isolated
Checking for live stock

This is manufactured by Analog Devices Inc.. The manufacturer part number is DC3020A. Basic Purpose: dc/dc, step down. It is assigned with possible HTSUS value of 8543.70.9860. The product is rohs3 compliant. The possible product's input voltage is 5.8v ~ 42v. The switching frequency of the standard product is 2mhz. In addition, it is reach unaffected. While, the output current includes 5a. The analog devices inc.'s product offers user-desired applications. It is a fully populated type. Its typical moisture sensitivity level is not applicable. It has a long 10 weeks standard lead time. The product offers buck regulator topology. Additionally, [Utilised IC / Part] is the used part of the product. Furthermore, the output voltage is 5v. In addition, bulk is the available packaging type of the product. The product is also supplied with contents, such as board(s). The product is designated with the ear99 code number. The output and type include 1, non-isolated.

pdf icon
DC3020A Schematic(Design Resources)
pdf icon
DC3020A Demo Manual(Manuals)
