Analog Devices Inc. DC2190A-B

Analog Devices Inc.

Product Information

Main Purpose:
DC/DC, Step Down
HTSUS:
8504.40.9580
RoHS Status:
ROHS3 Compliant
Note:
-
Voltage - Input:
16V ~ 55V
Frequency - Switching:
140kHz
title:
DC2190A-B
REACH Status:
REACH Unaffected
Current - Output:
30A
Manufacturer:
Analog Devices Inc.
Board Type:
Fully Populated
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
10 Weeks
Regulator Topology:
Buck
Utilized IC / Part:
LTC3892
Series:
PolyPhase®
Voltage - Output:
12V
Packaging:
Box
Supplied Contents:
Board(s)
ECCN:
EAR99
Base Product Number:
DC2190
Outputs and Type:
1, Non-Isolated
Checking for live stock

This is manufactured by Analog Devices Inc.. The manufacturer part number is DC2190A-B. Basic Purpose: dc/dc, step down. It is assigned with possible HTSUS value of 8504.40.9580. The product is rohs3 compliant. The possible product's input voltage is 16v ~ 55v. The switching frequency of the standard product is 140khz. In addition, it is reach unaffected. While, the output current includes 30a. The analog devices inc.'s product offers user-desired applications. It is a fully populated type. Its typical moisture sensitivity level is 1 (unlimited). It has a long 10 weeks standard lead time. The product offers buck regulator topology. Additionally, [Utilised IC / Part] is the used part of the product. The product polyphase®, is a highly preferred choice for users. Furthermore, the output voltage is 12v. In addition, box is the available packaging type of the product. The product is also supplied with contents, such as board(s). The product is designated with the ear99 code number. Moreover, it corresponds to dc2190, a base product number of the product. The output and type include 1, non-isolated.

pdf icon
DC2190A Schematic(Design Resources)
pdf icon
DC2190A Demo Manual(Manuals)
pdf icon
LTC3892(Datasheets)
