Number of Outputs:
1 (Pulse)
Display Type:
LCD
Meter Type:
Energy Meter
Cutout Width:
68mm
Number of Inputs:
3 x (Current Transformers) 3 x (Voltage) and Neutral
Maximum Measurement:
519 (Phase) V ac, 300 (Phase and Neutral) V ac, 6A, 65Hz
Approvals:
IEC/EN62053-21, IEC/EN62053-23, IEC/EN61326-1, IEC/EN55011 Class A, IEC/EN61000-4-2, IEC/EN61000-4-3, IEC/EN61000-4-4, IEC/EN61000-4-5, IEC/EN61000-4-6, IEC/EN61000-4-8, IEC/EN61000-4-11, IEC/EN61010
Measurement Range:
19→519 (Phase) V ac, 45→65Hz, 5A, 11→300 (Phase and Neutral)V ac
Digit Height:
5 mm
Communication Port Type:
Modbus RS485
Meter Accuracy:
±0.5 (Current) %, ±0.5 (Voltage) %, ±Class 1 (Active Energy)
Depth:
90mm
Maximum Temperature:
+55°C
Pulse Output:
Yes
Minimum Temperature:
-10°C
Cutout Height:
68mm
Number of Phases:
1, 3
Minimum Measurement:
19 (Phase) V ac, 11 (Phase and Neutral) V ac, 45 Hz, 0.2% Nominal
