Number of Outputs:
2 (Pulse)
Display Type:
LCD
Meter Type:
Energy Meter
Cutout Width:
70mm
Number of Inputs:
3 x (Current 100A Direct Connected) 3 x (Voltage) and Neutral
Maximum Measurement:
495 (Phase) V ac, 285 (Phase and Neutral) V ac, 100A, 65Hz
Approvals:
IEC/EN62053-21, IEC/EN50470-3, IEC/EN62053-23, IEC/EN50470, IEC/EN61326-1, IEC/EN55011 Class A, IEC/EN61000-4-2, IEC/EN61000-4-3, IEC/EN61000-4-4, IEC/EN61000-4-5, IEC/EN61000-4-6, IEC/EN61000-4-8, IEC/EN61000-4-11, IEC/EN50470-1/3, IEC/EN61010, IEC/EN62053-31
Measurement Range:
150→495 (Phase) V ac, 45→65Hz, 40 mA→100A, 85→285 (Phase and Neutral)V ac
Digit Height:
6.35 mm
Communication Port Type:
Modbus RS485
Meter Accuracy:
±0.5 (Current) %, ±0.5 (Voltage) %, ±Class B (Active Energy)
Depth:
66.3mm
Maximum Temperature:
+55°C
Pulse Output:
Yes
Minimum Temperature:
-25°C
Cutout Height:
90mm
Number of Phases:
1, 3
Minimum Measurement:
150 (Phase) V ac, 85 (Phase and Neutral) V ac, 45 Hz, 40mA
