EDAC Inc. 305-052-521-558

305-052-521-558 EDAC Inc.
EDAC Inc.

Product Information

Flange Feature:
Flush Mount, Top Opening, Threaded Insert, 4-40
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Material - Insulation:
Polyester Thermoplastic
Card Thickness:
0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Positions/Bay/Row:
26
Contact Finish Thickness:
10.0µin (0.25µm)
Number of Positions:
52
Card Type:
Non Specified - Dual Edge
REACH Status:
REACH Unaffected
edacadModel:
305-052-521-558 Models
Number of Rows:
2
edacadModelUrl:
/en/models/10856478
Package:
Box
Gender:
Female
Contact Finish:
Gold
Moisture Sensitivity Level (MSL):
Not Applicable
Termination:
Solder
standardLeadTime:
18 Weeks
Termination Rows:
2
Features:
-
Mounting Type:
Panel Mount, Through Hole
Color:
Green
Series:
305
Operating Temperature:
-40°C ~ 105°C
Read Out:
Dual
Pitch:
0.156" (3.96mm)
Contact Type:
Semi Bellows
Contact Material:
Copper Alloy
Base Product Number:
305-052
ECCN:
EAR99
Checking for live stock

This is manufactured by EDAC Inc.. The manufacturer part number is 305-052-521-558. Furthermore, flush mount, top opening, threaded insert, 4-40 is the Flange Feature of the product. It is assigned with possible HTSUS value of 8536.69.4040. The product is rohs3 compliant. It is designed from highly reliable polyester thermoplastic insulating material. A typical product' card thickness is 0.054" ~ 0.070" (1.37mm ~ 1.78mm). It has 26 positions. It has 10.0µin (0.25µm) of contact finishing thickness. The product carries possible position value of 52. The product features a non specified - dual edge card type. In addition, it is reach unaffected. It comes in 2 of rows. It is shipped in box package . In addition, female is the available "Gender" of the product. Furthermore, the product is galvanized with excellent gold contact finishing. Its typical moisture sensitivity level is not applicable. The product features solder termination style. It has a long 18 weeks standard lead time. Additionally, the bespoke product is available as 2 terminal(s). The product is available in panel mount, through hole configuration. It has a classic green colour. The product 305, is a highly preferred choice for users. The product has -40°c ~ 105°c operating temperature range. It features dual read values. Moreover, the product is 0.156" (3.96mm). It has typical contact type of semi bellows. The product is made from sturdy copper alloy materials. Moreover, it corresponds to 305-052, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
305,315,355 Series Ordering Guide(Datasheets)
pdf icon
305-052-521-558 Drawing(Product Drawings)
pdf icon
EDAC REACH(Environmental Information)
