Samtec MB1 Series, Female PCB Edge Connector SMT, 20 Way, 1 Row, 1mm Pitch

MB1-120-01-L-S-02-SL Samtec MB1 Series, Female PCB Edge Connector SMT, 20 Way, 1 Row, 1mm Pitch
Samtec

Product Information

Series:
MB1
Minimum Operating Temperature:
-55°C
Mounting Type:
Surface Mount
Gender:
Female
Body Orientation:
Straight
Termination Method:
Solder
Length:
26.06mm
Housing Material:
Liquid Crystal Polymer
Width:
5.44mm
Depth:
25.5mm
Number of Rows:
1
Contact Plating:
Gold over Nickel
Pitch:
1mm
Number of Contacts:
20
Maximum Operating Temperature:
+125°C
Contact Material:
Beryllium Copper
RoHs Compliant
Checking for live stock

This is MB1 Series Female PCB Edge Connector SMT 20 Way 1 Row 1mm Pitch manufactured by Samtec. The manufacturer part number is MB1-120-01-L-S-02-SL. The product mb1, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -55°c. The product is available in surface mount configuration. In addition, female is the available "Gender" of the product. It has straight body orientation. It allows solder termination method. Its accurate length is 26.06mm. The product also features robust liquid crystal polymer housing material. Furthermore, the product is 5.44mm wide. The product comes in 25.5mm depth. It comes in 1 of rows. The high-quality gold over nickel is used as contact plating material. Moreover, the product is 1mm. The product contains 20 contacts. It has a maximum operating temperature of +125°c. The product is made from sturdy beryllium copper materials.

pdf icon
MB1 Series Mini Card Edge Socket with Guides Catalogue Page(Technical Reference)
pdf icon
MB1 Series Mini Card Edge Socket with Guides Customer Drawing(Technical Reference)
pdf icon
MB1 Series Mini Card Edge Socket with Guides Footprint Drawing(Technical Reference)
