Dimensions:
2 x 1.25 x 1mm
Mounting Type:
Surface Mount
Diode Technology:
Schottky
Maximum Continuous Forward Current:
200mA
Peak Reverse Recovery Time:
5ns
Peak Non-Repetitive Forward Surge Current:
600mA
Maximum Forward Voltage Drop:
800mV
Height:
1mm
Peak Reverse Current:
10mA
Width:
1.25mm
Length:
2mm
Package Type:
SC-70
Number of Elements per Chip:
2
Minimum Operating Temperature:
-65 °C
Diode Type:
Schottky
Maximum Operating Temperature:
125 °C
Diode Configuration:
Series
Pin Count:
3
Peak Reverse Repetitive Voltage:
30V
HTSUS:
8541.10.0070
Package / Case:
SC-70, SOT-323
Diode Configuration:
1 Pair Series Connection
Operating Temperature - Junction:
-55°C ~ 125°C
Speed:
Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr):
5 ns
Voltage - Forward (Vf) (Max) @ If:
800 mV @ 100 mA
Package:
Bulk
Voltage - DC Reverse (Vr) (Max):
30 V
Current - Average Rectified (Io) (per Diode):
200mA (DC)
Current - Reverse Leakage @ Vr:
2 µA @ 25 V
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
SC-70-3 (SOT323)
Technology:
Schottky
Base Product Number:
BAT54
ECCN:
EAR99
