AC or DC Output Voltage:
dc
Output Current:
5A
Mounting Type:
DIN Rail Mount
Series:
DRL
AC or DC Input Voltage:
ac
Height:
123.6mm
Width:
30mm
Depth:
116.8mm
Input Voltage:
90 → 264V ac
Output Voltage:
24V dc
Power Rating:
120W
Type:
Switched Mode
HTSUS:
8504.40.9520
RoHS Status:
ROHS3 Compliant
Voltage - Output 1:
24V
Power (Watts):
120W
Current - Output (Max):
5A
Approval Agency:
CB, CCC, CE, cURus, EAC, KC, UKCA
Input Type:
AC
Applications:
ITE (Commercial), Laboratory
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
REACH Status:
REACH Affected
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
88.5%
DC Voltage - Input (Max):
-
Package:
Box
DC Voltage - Input (Min):
-
Minimum Load Required:
-
Size / Dimension:
4.87" L x 1.18" W x 4.60" H (123.7mm x 30.0mm x 116.8mm)
standardLeadTime:
32 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
90 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Adjustable Output, PFC, Universal Input
Series:
DRL (120W)
Operating Temperature:
-30°C ~ 70°C (With Derating)
Standard Number:
60950-1; 61010-1; 62368-1
Number of Outputs:
1
ECCN:
EAR99
