Number of Outputs:
1
Ripple And Noise:
<50mV
Output Current:
6A
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, cULus Recognized, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61204, IEC 61558-2-16, TUV, VDE 0100-410/DIN57100-410, VDE 0106-101
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+70°C
Series:
PRO MAX
Electrical Phase:
1
Special Features:
Durable, High Performance
AC or DC Input Voltage:
ac, dc
Height:
130mm
Width:
32mm
Depth:
125mm
MTBF:
>500000h
Output Voltage:
12V dc
Minimum Temperature:
-25°C
AC or DC Output Voltage:
dc
Power Rating:
72W
Type:
Switched Mode
Input Voltage:
85 → 277 V ac / 80 → 370V dc
Manufacturer Standard Lead Time:
6 Weeks
Size / Dimension:
4.92" L x 1.26" W x 5.12" H (125.0mm x 32.0mm x 130.0mm)
Detailed Description:
Enclosed AC DC Converters 1 Output 12V 6A 85 ~ 277 VAC, 80 ~ 370 VDC Input
Voltage - Isolation:
4kV
Features:
Adjustable Output, IP20
Mounting Type:
DIN Rail
Applications:
ITE (Commercial)
Series:
PRO MAX (72W)
Customer Reference:
Voltage - Output 1:
12V
Packaging:
Bulk
Efficiency:
89%
Power (Watts):
72W
Current - Output (Max):
6A
Approval Agency:
CE, cULus, cuRus, EAC, TUV
Voltage - Input:
85 ~ 277 VAC, 80 ~ 370 VDC
Operating Temperature:
-25°C ~ 70°C
Type:
Enclosed
Number of Outputs:
1
Manufacturer:
Weidmüller
