Maximum Temperature:
+71°C
AC or DC Output Voltage:
dc
Dimensions:
36 x 55.6 x 94mm
Minimum Temperature:
-20°C
AC or DC Input Voltage:
ac
Width:
36mm
Electrical Phase:
1
Type:
Switched Mode
Load Regulation:
120mV
Standards Met:
IEC 60068-2-27, IEC 60068-2-6, UL 1310, UL 508, UL 60950-1
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
12 → 15V
Ripple And Noise:
120mV
Depth:
55.6mm
Special Features:
High In-Service Lifetime, Low No Load Consumption
Output Current:
2.1A
Mounting Type:
DIN Rail Mount
Series:
DRL-30
Height:
91mm
Output Voltage:
12V dc
Power Rating:
30W
HTSUS:
8504.40.9510
RoHS Status:
RoHS Compliant
Voltage - Output 1:
12V
Power (Watts):
30W
Current - Output (Max):
2.1A
Approval Agency:
CE
Input Type:
AC or DC
title:
DRL30-12-1
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
REACH Status:
REACH Unaffected
Voltage - Output 2:
-
Voltage - Output 3:
-
edacadModel:
DRL30-12-1 Models
Efficiency:
88%
Applications:
Hazardous Locations, ITE (Commercial)
edacadModelUrl:
/en/models/6561044
Manufacturer:
TDK-Lambda
DC Voltage - Input (Max):
373V
DC Voltage - Input (Min):
120V
Minimum Load Required:
-
Size / Dimension:
2.19" L x 1.42" W x 3.58" H (55.6mm x 36.1mm x 90.9mm)
standardLeadTime:
24 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
Adjustable Output, Universal Input
Series:
DRL (10-100W)
Operating Temperature:
-20°C ~ 71°C (With Derating)
Packaging:
Bulk
Base Product Number:
DRL30
Number of Outputs:
1
ECCN:
EAR99
