Number of Rows:
3
Row Loading:
a/c/e
Current Rating:
6A
Contact Plating:
Gold over Nickel
Maximum Contact Resistance:
15mΩ
Minimum Operating Temperature:
-55°C
Gender:
Female
Body Orientation:
Straight
Pitch:
5.08mm
Termination Method:
Solder
Housing Material:
Thermoplastic
Class Rating:
C2
3D Model:
https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=22330&DisplayLogo=False
Series:
09 05
Number of Contacts:
48
Type:
E
Maximum Operating Temperature:
+125°C
Contact Material:
Copper Alloy
Style:
E
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Material - Insulation:
Thermoplastic, Glass Filled
Operating Temperature:
-
Contact Finish Thickness:
-
Number of Positions:
48 (Power)
REACH Status:
REACH Unaffected
edacadModel:
09052486831 Models
Number of Rows:
3
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3179827
Manufacturer:
HARTING
Connector Type:
Receptacle, Female Sockets
Contact Finish:
Gold
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Level, Class:
2
Termination:
Solder
standardLeadTime:
8 Weeks
Current Rating (Amps):
-
Features:
-
Mounting Type:
Panel Mount, Through Hole
Series:
DIN 41612
Packaging:
Box
Pitch:
0.200" (5.08mm)
Number of Positions Loaded:
All
ECCN:
EAR99
