Analog Devices AD7837ANZ, 2-channel 12 bit Parallel DAC, 250ksps, 24-Pin PDIP

Enrgtech Part No: ET16757306
|
Manufacturer Part No:
AD7837ANZ
|
Manufacturer: Analog Devices

AD7837ANZ Analog Devices , 2-channel 12 bit Parallel DAC, 250ksps, 24-Pin PDIP

Product Information

Conversion Rate:

250ksps

Integral Nonlinearity Error:

±1LSB

Dimensions:

31.19 x 6.61 x 3.3mm

Mounting Type:

Through Hole

Number of DAC Channels:

Power Supply Type:

Dual

Minimum Operating Temperature:

-40 °C

Maximum Settling Time:

5µs

Digital Interface Type:

Parallel

Package Type:

PDIP

Architecture:

Segmented

Output Polarity:

Bipolar, Unipolar

Checking for live stock

This is 2-channel 12 bit Parallel DAC 250ksps 24-Pin PDIP manufactured by Analog Devices. The manufacturer part number is AD7837ANZ. Its conversion rate is 250ksps . Its integral nonlinearity error is ±1lsb . The given dimensions of the product include 31.19 x 6.61 x 3.3mm. The product is available in through hole configuration. Additionally, it includes 2 standard DAC channels . It is a type of dual power supply. Whereas, the minimum operating temperature of the product is -40 °c. The product has a maximum 5µs setting time . Additionally, the product has a/an parallel type digital interface . The package is a sort of pdip. The product has been designed as segmented. It has bipolar, unipolar polarity . The product has internal voltage reference. It has a maximum operating temperature of 85 °c. Features 12 bit resolution. It contains 24 pins.

Digital to Analog Converters ICs Solutions Bulletin, Volume 11, Issue 5(Technical Reference)

AD7837_7847, Dual 12-Bit MDACs, Data Sheet(Technical Reference)

ESD Control Selection Guide V1(Technical Reference)
