Dimensions:
82 x 164 x 44mm
Capacitance Measurement Resolution:
1pF
DC Current Measurement Resolution:
0.1µA dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Application:
Electrical, Industrial
Battery Life:
300 h
Best Resistance Measurement Accuracy:
±0.7% + 2 Digits
AC Current Measurement Resolution:
1mA ac
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
750V ac
Model Number p:
IDM72
Resistance Measurement Resolution:
100mΩ
Best AC Voltage Accuracy:
±0.9% + 5 Digits
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
500Hz
Absolute Maximum Capacitance Measurement:
6mF
Battery Type:
9V
Absolute Maximum Resistance Measurement:
60MΩ
Maximum Operating Temperature:
+50°C
Best Capacitance Measurement Accuracy:
±1.9% + 8 Digits
Minimum Operating Temperature:
0°C
Safety Category Level:
CAT IV
Length:
82mm
Calibrated:
UKAS
Absolute Maximum DC Current Measurement:
10A dc
AC Voltage Measurement Resolution:
0.1mV ac
Best DC Current Accuracy:
±1% + 2 Digits
Weight:
400g
Width:
164mm
Best AC Current Accuracy:
±1.5% + 5 Digits
Safety Category Voltage:
600V
Multimeter Type:
Handheld
Height:
44mm
Safety Category:
CAT IV 600 V
Best DC Voltage Accuracy:
±0.5% + 2 Digits
DC Voltage Measurement Resolution:
0.1mV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
