Maximum Temperature:
+70°C
Number of Outputs:
1
Minimum Temperature:
-30°C
Output Current Range:
0 → 9.6A
Holdup Time:
20ms
Standards Met:
ANSI/AAMI ES60601-1/ES60601-1-11, AU/NZ MEPS, CAN ICES-3(B)/NMB-3(B), CB, CE Certified, CoC Version 5, CUL Listed, CULus Recognized, EISA 2007/DoE, EN 55011(CISPR11) class B, EN 55024, EN 60601-1-2, EN 61000-3-2,3, EN 61000-4-2,3,4,5,6,8,11, EN 61204-3, EU ErP, FC, FCC Part 15 class B, IEC 320-C8, MIL-HDBK-217F, NRCan, PFC, TUV EN 60601-1, TUV EN 60601-1-11, TUV Rheinland Certified, VI
Input Connector:
IEC320-C8
Energy Efficiency Level:
VI
Overall Length:
175mm
Overall Depth:
35mm
Priced to Clear:
Yes
Operating Temperature Range:
-30 → +70 °C
Rated Output Power:
144W
Output Voltage Rating:
15 V dc
Medical Approved:
Yes
Overall Dimensions:
175 x 72 x 35mm
Weight:
660g
Series:
GSM160B
Overall Width:
72mm
Cable Length:
1200mm
Output Connection Type:
DC Plug
Load Regulation Range:
-5 → +5%
Input Voltage Range:
80 → 264 V ac, 113 → 370 V dc
