Number of Outputs:
1
Load Regulation:
±0.5%
Isolation Voltage:
3kV dc
Efficiency:
89.5%
Mounting Type:
Through Hole
Package:
Full Brick
Maximum Temperature:
+85°C
Series:
QHL750
Input Voltage Range:
200 → 425 V dc
Length:
116.8mm
Width:
61mm
Depth:
12.7mm
Output Voltage:
12V dc
Minimum Temperature:
-40°C
Input Voltage Nominal:
300 V dc
Power Rating:
750W
Output Current:
62.5A
Standards Met:
EN 50121-3-2, EN 50155, EN 55024, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 62368-1, IEC/EN 60068-2-1, IEC/EN 60068-2-2, IEC/EN 60068-2-30, IEC/EN 61373, IEC60571, MIL-HDBK-217F, UL/cUL 62368-1
Base Product Number:
QHL750300
HTSUS:
8504.40.9580
RoHS Status:
ROHS3 Compliant
Supplier Device Package:
Full Brick
Power (Watts):
750 W
Current - Output (Max):
62.5A
Package / Case:
Full Brick
Voltage - Input (Min):
200V
Type:
Isolated Module
Applications:
ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 1:
12V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
89.5%
Voltage - Input (Max):
425V
Package:
Box
Size / Dimension:
4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm)
standardLeadTime:
18 Weeks
Voltage - Isolation:
3 kV
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Mounting Type:
Through Hole
Series:
QHL750 (750W)
Operating Temperature:
-40°C ~ 85°C
Standard Number:
62368-1
Number of Outputs:
1
ECCN:
EAR99
