Number of Outputs:
1
Load Regulation:
±0.2%
Isolation Voltage:
2.25kV dc
Standards Met:
CE Certified, cULus Recognized, EN 50155, EN 55011, EN 55022, EN 61373, EN50121-3-2, EN60068-2-1, EN60068-2-2, EN60068-2-30, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, UL 60950-1
Mounting Type:
Through Hole
Package:
Quarter Brick
Maximum Temperature:
+100°C
Series:
RDQ
Input Voltage Range:
66 → 160 V dc
Length:
57.9mm
Railway Approved:
Yes
Width:
36.8mm
Depth:
12.7mm
Output Voltage:
12V dc
Medical Approved:
No
Minimum Temperature:
-40°C
Input Voltage Nominal:
110 V dc
Power Rating:
100W
Output Current:
8.4A
HTSUS:
8504.40.9580
RoHS Status:
ROHS3 Compliant
Power (Watts):
100 W
Current - Output (Max):
8.4A
Package / Case:
8-DIP Module
Voltage - Input (Min):
66V
Type:
Isolated Module
Applications:
ITE (Commercial), Railway
Voltage - Output 1:
12V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
90%
Voltage - Input (Max):
160V
Control Features:
Enable, Active High
Size / Dimension:
2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm)
Voltage - Isolation:
2.25 kV
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Remote On/Off, OTP, OVP, SCP, UVLO
Mounting Type:
Through Hole
Series:
RDQ (100W)
Operating Temperature:
-40°C ~ 100°C
Packaging:
Bulk
Base Product Number:
RDQ100110
Number of Outputs:
1
ECCN:
EAR99
