Sanyo Denki America Inc. 9W1TN48P1H01

9W1TN48P1H01 Sanyo Denki America Inc.
Sanyo Denki America Inc.

Product Information

Material - Blade:
Plastic
HTSUS:
8414.59.6560
RoHS Status:
ROHS3 Compliant
Width:
35.00mm
Power (Watts):
15.4 W
Air Flow:
135.0 CFM (3.78m³/min)
Approval Agency:
CSA, TUV, UL
Voltage Range:
36 ~ 55.2VDC
Noise:
59.0dB(A)
Voltage - Rated:
48VDC
Bearing Type:
Ball
edacadModel:
9W1TN48P1H01 Models
edacadModelUrl:
/en/models/6191298
Operating Temperature:
-4 ~ 158°F (-20 ~ 70°C)
RPM:
3800 RPM
Lifetime @ Temp.:
Varies Based on Temperature
Static Pressure:
1.578 in H2O (393.1 Pa)
Package:
Box
Size / Dimension:
Round - 150mm Dia
Termination:
4 Wire Leads
standardLeadTime:
18 Weeks
Current Rating (Amps):
0.320A
Moisture Sensitivity Level (MSL):
Not Applicable
Ingress Protection:
IP54 - Dust Protected, Water Resistant
Features:
PWM Control, Speed Sensor (Tach)
Weight:
0.728 lb (330.22 g)
Series:
San Ace 150W
Material - Frame:
Aluminum
Fan Type:
Motorized Impellers
Base Product Number:
9W1TN48
ECCN:
EAR99
Checking for live stock

This is manufactured by Sanyo Denki America Inc.. The manufacturer part number is 9W1TN48P1H01. The blades are constructed from robust plastic materials. It is assigned with possible HTSUS value of 8414.59.6560. The product is rohs3 compliant. Furthermore, the product is 35.00mm wide. The product features power and watts of 15.4 w. It has a 135.0 cfm (3.78m³/min) air flow rate. It is approved by csa, tuv, ul. While the voltage range is 36 ~ 55.2vdc. It has noise values of 59.0db(a). It also exhibits voltage rating of 48vdc. This has integrated with a ball, a bearing with long-lasting features. The product has -4 ~ 158°f (-20 ~ 70°c) operating temperature range. It provides maximum rpm up to 3800 rpm. This product offers longer life span for varies based on temperature. The product has a 1.578 in h2o (393.1 pa) static pressure. It is shipped in box package . The product's diameters include round - 150mm dia. The product features 4 wire leads termination style. It has a long 18 weeks standard lead time. Additionally, the product's output is 0.320a. Its typical moisture sensitivity level is not applicable. It is IP rated with ip54 - dust protected, water resistant. The splendid features of the product include pwm control, speed sensor (tach). The typical product's weight is 0.728 lb (330.22 g). The product san ace 150w, is a highly preferred choice for users. The frame of the product is made from highly durable aluminum materials. The latest designed fan is a type of motorized impellers offering unmatchable applications. Moreover, it corresponds to 9w1tn48, a base product number of the product. The product is designated with the ear99 code number.
