Shell Size, Connector Layout:
3 (DB, B) - 5W5
Flange Feature:
Housing/Shell (4-40)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub, Combo
Contact Finish Thickness:
15.0µin (0.38µm)
Dielectric Material:
Polybutylene Terephthalate (PBT), Glass Filled
Number of Positions:
5 (Power)
REACH Status:
REACH Unaffected
edacadModel:
630W5W5-340-1N3 Models
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/13857314
Voltage Rating:
125V
Wire Gauge:
-
Contact Form:
-
Connector Type:
Receptacle, Female Sockets
Contact Finish:
Gold
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
standardLeadTime:
18 Weeks
Current Rating (Amps):
10A
Backset Spacing:
-
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Board Lock, Mounting Brackets, Shielded
Mounting Type:
Panel Mount, Through Hole, Right Angle
Color:
Black
Series:
630-WC
Shell Material, Finish:
Steel, Nickel Plated
Packaging:
Tray
Contact Type:
Power
Contact Material:
Copper Alloy
Base Product Number:
630W5W
ECCN:
EAR99
