Series:
D-Sub Standard
Current Rating:
6.5A
Dimensions:
31.2 x 15 x 12.5mm
Mounting Type:
Through Hole
Number of Contacts:
9
Gender:
Female
Body Orientation:
Right Angle
Termination Method:
Solder
Length:
31.2mm
Housing Material:
Steel
Width:
15.0mm
Depth:
12.5mm
Minimum Operating Temperature:
-55.0°C
Pitch:
2.74mm
Mounting Hardware:
Boardlocks, M3 Threaded Inserts
Contact Material:
Copper Alloy
Maximum Operating Temperature:
+125°C
Series Number:
966
Shell Size, Connector Layout:
1 (DE, E)
Flange Feature:
Housing/Shell (M3)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub
Contact Finish Thickness:
-
Dielectric Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Number of Positions:
9
REACH Status:
REACH Unaffected
edacadModel:
09661526611 Models
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3181103
Voltage Rating:
-
Wire Gauge:
-
Contact Form:
Stamped
Connector Type:
Receptacle, Female Sockets
Contact Finish:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
standardLeadTime:
8 Weeks
Current Rating (Amps):
6.5A
Backset Spacing:
0.409" (10.40mm)
Ingress Protection:
-
Features:
Board Lock
Mounting Type:
Through Hole, Right Angle
Color:
-
Series:
-
Shell Material, Finish:
Steel
Packaging:
Tray
Contact Type:
Signal
Contact Material:
Copper Alloy
ECCN:
EAR99
