chainflex PVC Control Cable (9G0.5)C

CF6-05-09--50m- chainflex PVC Control Cable (9G0.5)C
CF6.05.09 (50m)
CF6.05.09 (50m)
ET21589770
ET21589770
Igus

Product Information

Screened/Unscreened:
Screened
Earth Cable:
Yes
Conductor Resistance:
39 Ω/km
Oil Resistant:
Yes
American Wire Gauge:
20 AWG
Number of Cores:
9
Outer Diameter:
12mm
Sheath Material:
PVC
Cable Shape:
Multicore
Maximum Operating Temperature:
+70°C
Voltage Rating:
300/500 V
Minimum Bend Radius:
4 x D
Fire Behaviour:
Flame Retardant
Armoured:
No
Length:
50m
Current Rating:
8 A
Screen Type:
Tinned Copper Braid
Conductor Material:
Copper
Series:
chainflex CF6
Sheath Colour:
Green
Cross Sectional Area:
0.5 mm²
Minimum Operating Temperature:
-15°C
Insulation Material:
PVC
RoHs Compliant
Checking for live stock

This is chainflex PVC Control Cable (9G0.5)C manufactured by Igus. The manufacturer part number is CF6.05.09 (50m). Screen Options - screened. It has an earth cable included yes . The conductor has 39 ω/km resistance. Additionally, it is oil resistant yes . Features 20 awg - American Wire Gauge. The product consists of 9 cores. Its outer diameter is 12mm. The sheath is constructed from durable and adorable pvc material. Moreover, this cable has a multicore shape. It has a maximum operating temperature of +70°c. Moreover, the product has a nominal 300/500 v voltage rating. It bears 4 x d of minimum bend radius. The product has a flame retardant fire behaviour. It is armoured no . Its accurate length is 50m. The product has a current rating of 8 a. It has a/an tinned copper braid type screen . The conductor is made from copper material. The product chainflex cf6, is a highly preferred choice for users. The sheath has an adorable green colour. The product has 0.5 mm² cross section area. Whereas, the minimum operating temperature of the product is -15°c. It has a robust pvc insulation material.

pdf icon
Datasheet - CF6.05.09(Technical Reference)
pdf icon
Cable Selection Guide(Technical Reference)
pdf icon
CCC Statement - CF6(Technical Reference)
pdf icon
NFPA 79 - Update 2012 - CF6(Technical Reference)
pdf icon
Declaration of Conformity - CF6.05.09(Technical Reference)
pdf icon
REACH and ROHS - CF6(Technical Reference)
