Bourns PM3700 Series Type 3700 SMD Common Mode Choke with a Ferrite Core, 20 mH Wire-Wound 1A Idc

PM3700-80-RC Bourns PM3700 Series Type 3700 SMD Common Mode Choke with a Ferrite Core, 20 mH Wire-Wound 1A Idc
Bourns

Product Information

Dimensions:
17.78 (Dia.) x 11.43mm
Mounting Type:
Surface Mount
Maximum Current:
1 A
Series:
PM3700
Operating Temperature Range:
-55°C → +125°C
Termination Style:
Solder Pad
Height:
11.43mm
Test Frequency:
25 KHz → 4 MHz
Inductance:
20 mH
DC Resistance:
0.250Ω
Maximum Operating Temperature:
+125°C
Minimum Operating Temperature:
-55°C
Package/Case:
3700
RoHs Compliant
Checking for live stock

This is PM3700 Series Type 3700 SMD Common Mode Choke with a Ferrite Core 20 mH Wire-Wound 1A Idc manufactured by Bourns. The manufacturer part number is PM3700-80-RC. The given dimensions of the product include 17.78 (dia.) x 11.43mm. The product is available in surface mount configuration. It also carries 1 a maximum current. The product pm3700, is a highly preferred choice for users. The product has -55°c → +125°c of operating temperature range. Moreover, it has solder pad terminal style. In addition, the height is 11.43mm. It features a test frequency of 25 khz → 4 mhz. The product has a 20 mh inductance value. It has about 0.250ω DC resistance . It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -55°c. Concerning its package and casing, it is 3700.

pdf icon
PM3700 Series - SMD Common Mode Choke Data Sheet(Technical Reference)
