HTSUS:
8541.41.0000
RoHS Status:
ROHS3 Compliant
Viewing Angle:
120°
Package / Case:
24-SMD Module, No Lead
Current - Test:
700mA Red, 700mA Green, 700mA Blue, 700mA White
Current - Max:
1A Red, 1A Green, 1A Blue, 1A White
Height - Seated (Max):
0.059" (1.50mm)
REACH Status:
REACH Unaffected
Thermal Resistance of Package:
0.5°C/W
edacadModel:
LZP-04MD00-0000 Models
edacadModelUrl:
/en/models/5262446
Luminous Flux @ Current/Temperature:
493lm Red, 800lm Green, 170lm Blue, 1453lm White
Package:
Tray
Size / Dimension:
0.472" L x 0.472" W (12.00mm x 12.00mm)
Temperature - Test:
25°C
Voltage - Forward (Vf) (Typ):
15V Red, 21.6V Green, 19.2V Blue, 22.4V White
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Mounting Type:
Surface Mount
Color:
Red, Green, Blue, White - Cool (RGBW)
Series:
LZP
Supplier Device Package:
SMD
Lumens/Watt @ Current - Test:
47 lm/W Red, 53 lm/W Green, 13 lm/W Blue, 93 lm/W White
Wavelength:
624nm Red, 525nm Green, 457nm Blue, 6450K White
ECCN:
EAR99
