Dimensions:
258 x 103 x 55mm
Power Source:
Battery
Maximum Conductor Size:
40 Dia.mm
Width:
103mm
Battery Life:
50 h
Resistance Measurement Resolution:
100mΩ
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
1000V ac
Model Number:
157B
Best AC Voltage Accuracy:
±(1% rdg + 5dgts)
Connectivity:
Bluetooth
Absolute Maximum AC Current Measurement:
1000A ac
Battery Type:
1.5 V AAA, Alkaline
Absolute Maximum Resistance Measurement:
100kΩ
Maximum Operating Temperature:
+50°C
Non-Contact Voltage Detector:
Yes
Minimum Operating Temperature:
0°C
Safety Category Level:
CAT III, CAT IV
Length:
258mm
Calibrated:
RSCAL
Absolute Maximum Temperature Measurement:
+1000°C
Display Type:
Bar Graphs, LED
Best Resistance Measurement Accuracy:
±1 + 5 Digits %
Jaw Capacity Busbars:
33mm
Weight:
600g
Best AC Current Accuracy:
±(1.5% rdg + 5dgts)
Safety Category Voltage:
600 V, 1000V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
55mm
Safety Category:
CAT III 1000 V, CAT IV 600V
Best DC Voltage Accuracy:
±(0.7% rdg + 2dgts)
Clamp Meter Type:
Power Clamp Meter
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
