Dimensions:
78 x 51 x 235mm
Power Source:
Battery
DC Current Measurement Resolution:
100mA
Maximum Conductor Size:
35 (Dia.)mm
Width:
51mm
Battery Life:
50 h
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
100mA
Best Temperature Measurement Accuracy:
±1 %
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
IPM138N
Best AC Voltage Accuracy:
±(1% rdg + 5dgts)
Absolute Maximum AC Current Measurement:
600A ac
Battery Type:
9V, IEC 6F22, NEDA 1604
Absolute Maximum Resistance Measurement:
20kΩ
Maximum Operating Temperature:
+50°C
Jaw Capacity Busbars:
35mm
Safety Category Level:
CAT II, CAT III
Length:
78mm
Temperature Measurement Resolution:
0.1 °C, 1 °F
Absolute Maximum Temperature Measurement:
+1000 °C, +1832°F
Absolute Maximum DC Current Measurement:
600A dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1% + 5 Digits
Best DC Current Accuracy:
±(1% rdg + 5dgts)
Weight:
380g
AC Voltage Measurement Resolution:
100mV
Best AC Current Accuracy:
±(1% rdg + 5dgts)
Safety Category Voltage:
600 V, 1000 V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
235mm
Safety Category:
CAT II 1000 V, CAT III 600 V
Best DC Voltage Accuracy:
±(0.7% rdg + 5dgts)
DC Voltage Measurement Resolution:
100mV
Clamp Meter Type:
Power Clamp Meter
Minimum Operating Temperature:
0°C
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Power Factor, Resistance, Temperature, Total Harmonic Distortion, Wattage
