HTSUS:
8536.69.4020
RoHS Status:
RoHS non-compliant
Voltage Rating:
600VAC
Mounting Feature:
-
Operating Temperature:
-55°C ~ 125°C
Shell Size, MIL:
-
Number of Positions:
3
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Aluminum, Olive Drab Cadmium
Shielding:
Unshielded
Cable Opening:
0.125" (3.18mm)
Shell Material:
Aluminum
REACH Status:
REACH Affected
Current Rating (Amps):
-
Applications:
Aerospace, Industrial, Instrumentation, Mass Transit, Military
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bag
Shell Size - Insert:
8-3
Connector Type:
Receptacle, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Termination:
Solder Cup
standardLeadTime:
18 Weeks
Insert Material:
Neoprene
Orientation:
N (Normal)
Ingress Protection:
-
Features:
Backshell, Cable Clamp, Strain Relief
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
Olive Drab Chromate over Cadmium
Color:
Olive Drab
Series:
MIL-DTL-26482 Series I, PT
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Alloy
Base Product Number:
PT01A
ECCN:
EAR99
