Current Rating:
4A
Mounting Type:
Cable Mount
IP Rating:
IP67
Series:
SACC-FR-4SC M SCO
Body Orientation:
Right Angle
Voltage Rating:
250 V
Contact Gender:
Female
Housing Material:
Nylon
Plug/Socket:
Plug
Connector Size:
M12
Shell Size:
19mm
Number of Contacts:
4
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polyamide (PA66), Nylon 6/6
Shielding:
-
Cable Opening:
0.157" ~ 0.315" (4.00mm ~ 8.00mm)
Shell Material:
Zinc Die Cast
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Voltage Rating:
250V
Shell Size - Insert:
M12-4
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Twist
Termination:
Spring-Cage
Insert Material:
Thermoplastic Polyurethane (TPU)
Orientation:
A
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Angled
Shell Finish:
Nickel
Color:
Black, Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Tin
ECCN:
EAR99
